- -open design
- -process controlled direct water cooling of mould blocks
- -high outputs
- -multi zone vacuum technology
- -shuttle principle
- -parking station for in-line cuff production available
- -metrical and imperial mould block length available
- -mould blocks made of casted special aluminium alloy
- -easy and quick mould block change
- -precise lateral and height adjustment of corrugator
- -central lubrication with monitoring system
- -hydraulic buffered push off cylinder system
- -PLC control system
- -touch screen technology
- -graphic visualisation of process data
- -electrical control for synchronisation with extruder
- -maintenance-free servo motors
- -telediagnostic service via internet available
- -Storm water and sewage
- -Manholes
- -Conveyor pipes
- -Structural and civil engineering
Technical data
parameter | UC 1800/6 iV (PS im) |
max. pipe diameter (outer diameter) in mm | 1.800 |
min. pipe diameter (inner diameter) in mm | 500 |
connection power in kw | 120 |
amount of mould blocks | 6 + 1 (PS) |
mould block chain in total (mm) | 3.658 + 914 |
mould blocks in middle channel (mm) | 2.200 |
max. PVC output (KG) | 1.600 |
max. HDPE output (kg/h) | 1.350 |
max. speed (m/min) | 1.5 |
length (mm) | 7.400 |
width (mm) | 7.200 |
height (mm) | 5.000 |
weight (kg) | 40.000 |
PS = available with parking station (for 1 cuff mould block)
im = imperial execution
plastics
- -Polyolefines
- -PVC
